Double head 3kw Sticker Labeling Machine for 30mm 250mm lab

Double head 3kw Sticker Labeling Machine for 30mm 250mm label height

Quick Detail:

Driven Type: Electric

Voltage: 110/220/380V

Brand Name: Renda

Dimension(L*W*H): 2220*1100*2100mm

Weight:480kg

Certification: CE,ISO

Processing: labeling machine

Suitable Bottle: 0.25-2L

Material: stainless steel

Warranty: 1 year

After-sales Service Provided: Engineers available to service machinery oversea

Description:

The machine can be used in two ways. It not only reduces a trapping label machine, but also proves as cost effective for our clients;
It reduces the length of conveying line and avoids the secondary transportation, so that it increases the production efficiency and the capacity of floor area. of the equipment;
It also reduces stumbles in the process and increase the quality of product.
Applicable Variety Types of Casting Label, with the accurate casting label, the equipment applies to the casting label and sealing of bottles with various shapes and hexagonal oil drum, Suitable for larger bottle-type(3-5 liters barrel containers). The products are sold in quantity to the domestic and overseas markets.
It adopts equivalent PLC, positioning module, servo motor and frequency converter. In addition, its touch screen is featured with a humanized operation.

Specifications:

Input Power: 3.0KW
Input Voltage: 3,380/220VAC
Production Efficiency: 2X250Bottle/min
Size of Host Machine: 3200L*1200W*2070H
Applicable Diameter of Bottle Body: Φ28mm—Φ125mm
Applicable Length of Label: 30mm—250mm
Applicable Thickness of Label: 0.03mm—0.13mm
Applicable Internal Diameter of Paper Tube 5”—10”
