Foil Roll Carton Box Packaging Machinery CE with automatic alarm system
Full Automatic Kitchen Foil Roll Carton Box Packaging Machinery (CE)
Quick Detail:
Name |
FJ-450 Kitchen Foil Roll Box Packaging Line |
Brand Name |
FANRS |
Packing Speed |
45-50pcs/min
|
Feature |
Full automatic |
Operation |
PLC Digital Control System
|
Certificate |
CE,ISO,SGS |
Applications:
Our FJ-450 is mainly used in Aluminum Foil Kitchen Roll Carton box Packing. For more detail is that FJ-450 is specialised in packing the already kithen foil rolls into the carton box and glude seal the box on the both side, during the packing process, the FJ-450 also finish the work of folding the carton into box.
Description:
Our latest patent machine used to pack the aluminum kitchen foil roll into color box and then glue box both sides, which can improve production speed, save labor cost and improves competitiveness.
- Box feeding, open and gluing full automatically.
- Adapt PLC Digital Control system, operation easy, safe and reliable.
- With photoelectric tracking, each part could be monitored
- Glue system adapt automatic glue machine, viscosity high.
- Built with automatic alarm system and auto stop system.
- Completed with auto counting system, quantity could be speed on PLC.
Specifications:
Max.Roll Diameter |
48mm |
Max.Roll Width |
500mm |
Max.Box Size(LxWxH) |
500*50*50mm |
Min.Box Size(LxWxH) |
300*40*40mm |
Paper Box Request |
300-450g/m2 |
Speed |
45-50pcs/min |
Air Supply |
0.6-0.9Mpa |
Voltage |
AC380V /50Hz |
Total Power |
5.5kw |
Machine Weight |
1500kg |
Machine Dimension (L*W*H) |
3800*1800*1800mm |
Working Space (L*W*H) |
6000*4600*1800 |
Competitive Advantage:
I. We are professional Machine Manufacture sale directly
II. High quality with reasonable price
III. Good reputation at home and abroad
VI. We are provide technical support all lifelong
Some more pictures for your reference:
