Automatic PET Bottle Unscrambler Machine
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
Product Description
Product Description
Basic Specification
| Sorting bottle type | round or square bottle |
|---|---|
| Bottle material | PET/Plastic bottle |
| Unscrambling bottle capacity | 6000-28000b/h |
| Grade | full automatic |
| Apply to | juice bottle, water bottle, drinking bottle |
| Power | customized |
| Voltage | customized |
| Speed | 6000-28000b/h |
| Type | Overlay Wrapping Machine |
| Driven Type | Electric |
| Packaging Material | Wood |
| Automatic Grade | Automatic |
| Material | Stainless Steel |
| Application | Beverage, Food, Juice, Water |
| Size | 0.25-4L bottle |
| Packing Size | 0.25-2L |
Detail Description
Automatic PET Bottle Unsdcrambler Machine
Apply to;
-Automatic Bottle Unscrambler is able to tidy the random bottles and set them in good order to the conveying belt of the filling machine.
-It apply to PET water bottle, juice bottle, soft drinkinh bottle etc
-Our automatic bottle unscrambler machine capacity can reach to 28000b/h
Working principle:
When the bottle elevator is started, the disordered bottles will be transferred on top of umbrella shape tower, and then fall into bottle ascending-descending devices. The bottle ascending-descending devices will push bottles into bottle dropping grooves under the action of cam. Then the ordered bottles will be sent out through planet wheel into air conveyor. Planet wheel is connected with motor main axis by synchronous belt.
Main Technical Technology
Apply to;
-Automatic Bottle Unscrambler is able to tidy the random bottles and set them in good order to the conveying belt of the filling machine.
-It apply to PET water bottle, juice bottle, soft drinkinh bottle etc
-Our automatic bottle unscrambler machine capacity can reach to 28000b/h
Working principle:
When the bottle elevator is started, the disordered bottles will be transferred on top of umbrella shape tower, and then fall into bottle ascending-descending devices. The bottle ascending-descending devices will push bottles into bottle dropping grooves under the action of cam. Then the ordered bottles will be sent out through planet wheel into air conveyor. Planet wheel is connected with motor main axis by synchronous belt.
Main Technical Technology
1 |
Number of working positions |
14
|
2 |
Rationed capacity |
6000 bottles /hour
|
3 |
Max .capacity |
8000 bottles/ hour
|
4 |
Air pressure |
0.7MPa |
5 |
Air consumption |
1.5M3/ min
|
6 |
Applicable bottles. diameter |
50-96MM, |
7 |
Applicable bottles. Height |
165-300MM |
8 |
Main motor |
2.2KW
|
9 |
Lifting motor |
0.75KW |
10 |
Fan |
1.5KW
|
11 |
Dimension |
2150×2500*2340mm
|
12 |
Weight |
Approx 2500 Kg
|
Any further info for our automatic pet bottle unscrambler machine, pls contact us
