Suspended drinks filling machine

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Product Details

Basic Specification

Machine Material	Stainless Steel food grade
Pulp Juice Plant Included	Bottle washing, filling, capping, labeling, pack.
Power(w)	7.68KW
Voltage	380/220V
Packaging Material	Wood
Driven Type	Electric
Material	Stainless Steel
Weight	2000KG
Application	Beverage, Juice, Other
Number Of Filling Valves	24
Type	Negative Pressure Filling Machine
Automatic Grade	Automatic
Packaging Type	Bottles

Detail Description

Suspended drinks filling machine

This machine is special used for suspended drinks, grainy juice, and pulp juice bottling process.
It is consists of washing-pulp filling-juice filling-capping 4 parts (or separate)
Meanwhile, the pulp filler is piston filling type, It widely used for sauce and oil and other viscous material.
The filling capacity is 200ml-2000ml adjustable.

Technical Data:

Model	Number of washing filling and capping	Production capacity Bottle per hour(0.5L)	Applicable bottle specifications (mm)	Power(kw)	Dimension(mm)
RCGGF18/12/16/5	18, 12, 16, 5	5000-6000	0.25L-2L 50-108 mm H=170-340mm	7.68	3500x1400x2500
RCGGF24/16/24/8	24, 16, 24, 6	8000-10000	8.68	4460x1720x2650
RCGGF32/18/32/8	32, 18, 32, 8	10000-12000	10.18	5100x2100x2650
RCGGF40/24/40/10	40, 24, 40, 10	15000-16000	12.28	6100x4500x3400

Additional Information

Payment Terms	L/C, T/T
Minimum Order	1 Set
Lead Time / Delivery Time	70 Day(s)
Sample Available	NO
Delivery Details	We invite you come our factory to check machine before shipment.
FOB Port	Shanghai
Loading Info	Ship from Shanghai port.
Packing Info	Shrink film and wooden box.
Target Market(s)	Africa(except Middle East), Central & Southern Asia, Eastern Europe, Hong Kong/ Macao/ Taiwan, Japan & Korea, Latin America, Mainland China, Middle East, North America, Northern Europe, Oceania, Southeast Asia, Western & Southern Europe
