Bottle Liquid Packaging Solutions
Your message must be between 20 to 2000 characters
Contact NowBasic Specification
| Use | Bottle Liquid Packaging Solutions |
|---|---|
| Filling Capacity | 2000-20000BPH(0.5L) |
| Filling Liquid | Hot Drinks, Juice,Tea |
| Processing | Rinser Filler Sealer 3 in 1 |
| Filling Type | Gravity Hot Filling |
| Voltage | 380V/ 220V |
| Power(w) | 3.58KW |
| Packaging Material | Wood |
| Number Of Filling Valves | Other |
| Driven Type | Electric |
| Material | Stainless Steel |
| Weight | 2100KGS |
| Application | Beverage, Juice, Water |
| Type | Negative Pressure Filling Machine |
| Automatic Grade | Automatic |
| Packaging Type | Bottles |
Detail Description
Bottle Liquid Packaging Solutions
Bottle Liquid Packaging Solutions include water purification system, bottle washing filling cap sealing machine, labeling machine, code printer and packing machine.
According to your bottles and caps our machines are different.
Different liquid machine different also.
Products Introduction:
- RCGF series Bottled Juice Filling Plant is used for filling kinds of hot drinks in PET bottle, such as Orange Juice, Apple Juice, Tea, other hot drinks....
- It adopts rinsing/filling/capping 3-in-1 technology.
- Filling Capacity: 0.25-2L PET bottle
- Filling Principle: Gravity Hot Filling Type.
* We supply the complete Bottle Juice Filling Plant:
1- Water Treatment System
2- Juice Mixing System
3- Filling System
4- Labeling & Packing System
* Glass Bottle Juice Filling Machine picture & video, please check our web: www.hsfilling.net
Main Technology
| Model | Number of washing filling and capping | Production capacity Bottle per hour(0.5L) |
Applicable bottle specifications (mm) | Power(kw) | Dimension(mm) |
| RCGF14/12/5 | 14, 12, 5 | 2000-3000 | 0.25L-2L 50-108 mm H=170-340mm |
3.58 | 2100x1400x2500 |
| RCGF18/18/6 | 18, 18, 6 | 4000-6000 | 7.61 | 2460x1720x2650 | |
| RCGF24/24/8 | 24, 24, 8 | 6000-8000 | 8.2 | 3100x2100x2650 | |
| RCGF32/32/8 | 32, 32, 8 | 10000-12000 | 9.18 | 3500x2500x2650 | |
| RCGF40/40/10 | 40, 40, 10 | 13000-15000 | 10.28 | 4600x1800x2650 | |
| RCGF50/50/12 | 50, 50, 12 | 16000-18000 | 11.28 | 5200x4500x3400 | |
| RCGF60/60/15 | 60, 60, 15 | 20000-22000 | 11.28 | 6500x4500x3400 |
We also supply Glass Bottle Juice Filling Line, pls check below:
Related Video please check: www.hsfilling.net
Additional Information
| Payment Terms | L/C, T/T |
|---|---|
| Minimum Order | 1 Set |
| Lead Time / Delivery Time | 90 Day(s) |
| Sample Available | NO |
| Delivery Details | According Customer\'s Requirements |
| FOB Port | Shanghai |
| Loading Info | Sea Transportation |
| Packing Info | Film Wrap + Wooden Case |
| Target Market(s) | Africa(except Middle East), Central & Southern Asia, Eastern Europe, Hong Kong/ Macao/ Taiwan, Japan & Korea, Latin America, Mainland China, Middle East, North America, Northern Europe, Oceania, Southeast Asia, Western & Southern Europe |
