Automatic 3 in 1 Soft Drink Plant (Rinser, Filler, Capper Monblock)
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
Product Description
Product Description
Basic Specification
| filler | carbonated water, gas water, Coca-Cola, Fenda |
|---|---|
| filler type | isotonic filling machine |
| grade | full automatic |
| material of bottle | plastic/PET |
| Commodity | carbonated production line |
| Power | 9.68kw |
| Capacity | 80 sets/year |
| Quantity | 50 sets/year |
| Automatic | Y |
| Bottle Material | Glass, Plastic |
| Type | Carbonated Drinks Complete Sets Of Production Equipment |
| Liquid Type | Others, Water |
| Capacity | 10000-12000b/h |
| Speed | 1000-22000b/h |
| Volume | 0.25-2L bottle |
| Size | 0.25-2L |
Detail Description
Automatic 3 in 1 Soft Drink Plant (Rinser, Filler, Capper Monblock)
Products Introduction:
This DCGF bottled carbonated rinser fille capper used to produce PET bottled carbonated beverages (soda) production, such as Coca-Cola, Fenda, Sprite and gas-bearing mineral water.
Characteristics:
1. Using the wind sent access and move wheel in the bottle directly connected technology; canceled screw and conveyor chains, this enable the change the bottle-shaped become easier.
2. Bottles transmission adopt clip bottleneck technology, bottle-shaped transform not need to adjust the equipment level, only change related the curved plate, wheel and nylon parts is enough..
3. The specially designed stainless steel bottle washing machine clip is solid and durable, no touch with the screw location of bottle mouth to avoid secondary pollution.
4. The cylinder drive the valve the movements is accurate and reliable. High-throughput, high-precision filling valve, filling fast and accurate. Equipped the CIP loop and control procedures, the equipment is easy to clean.
5. Spiraling decline when output bottle, transform bottle shape no need to adjust the height of conveyor chains.
6. Using the programmable controller as control centers; using pressure transmitter, electromagnetic measurement to maintain the balance of liquid surface so as to ensure the stability of liquid.
7. New designing filling valve, return gas and filling liquid are separate to ensure the filling materials is clean.
8. The machine adopt advanced magnetic clutch screw lid and the torsion torque is adjustable, so screwing is safe and reliable.
Bottled Carbonated Rinser Filler Capper Main Technical Data:
Products Introduction:
This DCGF bottled carbonated rinser fille capper used to produce PET bottled carbonated beverages (soda) production, such as Coca-Cola, Fenda, Sprite and gas-bearing mineral water.
Characteristics:
1. Using the wind sent access and move wheel in the bottle directly connected technology; canceled screw and conveyor chains, this enable the change the bottle-shaped become easier.
2. Bottles transmission adopt clip bottleneck technology, bottle-shaped transform not need to adjust the equipment level, only change related the curved plate, wheel and nylon parts is enough..
3. The specially designed stainless steel bottle washing machine clip is solid and durable, no touch with the screw location of bottle mouth to avoid secondary pollution.
4. The cylinder drive the valve the movements is accurate and reliable. High-throughput, high-precision filling valve, filling fast and accurate. Equipped the CIP loop and control procedures, the equipment is easy to clean.
5. Spiraling decline when output bottle, transform bottle shape no need to adjust the height of conveyor chains.
6. Using the programmable controller as control centers; using pressure transmitter, electromagnetic measurement to maintain the balance of liquid surface so as to ensure the stability of liquid.
7. New designing filling valve, return gas and filling liquid are separate to ensure the filling materials is clean.
8. The machine adopt advanced magnetic clutch screw lid and the torsion torque is adjustable, so screwing is safe and reliable.
Bottled Carbonated Rinser Filler Capper Main Technical Data:
Model |
Number of washing filling and capping |
Production capacity |
Applicable bottle specifications (mm) |
Power(kw) |
Dimension(mm) |
DCGF14/12/5 |
14, 12, 5 |
2000-3000 |
0.25L-2L |
3.58 |
2100x1400x2500 |
DCGF18/18/6 |
18, 18, 6 |
4000-6000 |
4.68 |
2460x1720x2650 |
|
DCGF24/24/8 |
24, 24, 8 |
6000-8000 |
6.58 |
3100x2100x2650 |
|
DCGF32/32/8 |
32, 32, 8 |
10000-12000 |
9.68 |
3500x2500x2650 |
|
DCGF40/40/10 |
40, 40, 10 |
13000-15000 |
|
9.68 |
4600x1800x2650 |
DCGF50/50/12 |
50, 50, 12 |
16000-18000 |
10.8 |
5200x4500x3400 |
|
DCGF60/60/15 |
60, 60, 15 |
20000-22000 |
11.28 |
6500x4500x3400 |
Additional Information
| Payment Terms | L/C, T/T |
|---|---|
| Minimum Order | 1 |
| Lead Time / Delivery Time | 45 Day(s) |
| Sample Available | NO |
| Delivery Details | Within 45 days after received 30%T/T deposit, sample bottles and caps |
| FOB Port | Shanghai |
| Loading Info | sea transport |
| Packing Info | PE-Film, wooden case |
| Target Market(s) | Africa(except Middle East), Eastern Europe, Hong Kong/ Macao/ Taiwan, Japan & Korea, Latin America, Mainland China, Middle East, North America, Northern Europe, Oceania, Central & Southern Asia, Southeast Asia, Western & Southern Europe |
