Automatic Liquid Water Bottling Plant
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
Product Description
Product Description
Basic Specification
| Grade | full automatic water machine |
|---|---|
| Water bottle material | PET/plastic small bottle |
| Filler | pure water, mineral water, spring water, non-gas |
| Type | washing filling capping |
| Machine including | air conveyor, conveyor, cap sorting |
| Capacity | 80 sets/year |
| Quantity | 80 sets/year |
| Capacity | 5000-6000b/h |
| Power | 4.68kw |
| Liquid Type | Water |
| Automatic | Y |
| Bottle Material | Plastic |
| Type | Pure Water Complete Sets Of Production Equipment |
| Speed | 1000-28000b/h |
| Size | 0.25-2L |
| Volume | 0.25-20L |
Detail Description
Automatic Liquid Water Bottling Plant
Products Introduction:
The CGF series automatic liquid water bottle filling machine suitable for flavored water and other non-carbonated beverage as well.
The CGF Wash-filling-capping 3-in-1 machine can finish all the process from empty bottle rinsing, filling and sealing, it can reduce the materials and Outsiders touch time, improve the sanitary conditions, production capacity and high cost effective.
Technical Parameters:
Water Bottling Plant Flow Chart:
1.water bottle making machine
2.water treatment plant
3.air conveyor
4.water bottle washing filling capping machine
5.bottle conveyor
6.air dryer
7.shrink sleeve labeling machine+shrink tunnel
8.date printer machine
9.bottle shrink wrapping machine
Any further info for 3-in-1Drinking Water Washing Filling Capping Machine/plant/line/equipment, pls contact me
Products Introduction:
The CGF series automatic liquid water bottle filling machine suitable for flavored water and other non-carbonated beverage as well.
The CGF Wash-filling-capping 3-in-1 machine can finish all the process from empty bottle rinsing, filling and sealing, it can reduce the materials and Outsiders touch time, improve the sanitary conditions, production capacity and high cost effective.
Technical Parameters:
|
|
|
|
|
|
Model |
Number of washing filling and capping |
Production capacity |
Applicable bottle specifications (mm) |
Power(kw) |
Dimension(mm) |
CGF14/12/5 |
14, 12, 5 |
2000-4000 |
0.25L-2L |
3.58 |
2100x1400x2500 |
CGF18/18/6 |
18, 18, 6 |
5000-7000 |
4.68 |
2460x1720x2650 |
|
CGF24/24/8 |
24, 24, 8 |
8000-12000 |
6.58 |
3100x2100x2650 |
|
CGF32/32/8 |
32, 32, 8 |
12000-15000 |
9.68 |
3500x2500x2650 |
|
CGF40/40/10 |
40, 40, 10 |
15000-18000 |
9.68 |
4600x1800x2650 |
|
CGF50/50/12 |
50, 50, 12 |
20000-24000 |
10.8 |
5200x4500x3400 |
|
CGF60/60/15 |
60, 60, 15 |
25000-28000 |
11.28 |
6500x4500x3400 |
Water Bottling Plant Flow Chart:
1.water bottle making machine
2.water treatment plant
3.air conveyor
4.water bottle washing filling capping machine
5.bottle conveyor
6.air dryer
7.shrink sleeve labeling machine+shrink tunnel
8.date printer machine
9.bottle shrink wrapping machine
Any further info for 3-in-1Drinking Water Washing Filling Capping Machine/plant/line/equipment, pls contact me
Additional Information
| Payment Terms | L/C, T/T |
|---|---|
| Minimum Order | 1 |
| Lead Time / Delivery Time | 45 Day(s) |
| Sample Available | NO |
| Delivery Details | within 45 days after received 30% T/T deposit |
| FOB Port | Shanghai |
| Loading Info | sea transport |
| Packing Info | PE-Film, wooden case |
| Target Market(s) | Africa(except Middle East), Eastern Europe, Hong Kong/ Macao/ Taiwan, Japan & Korea, Latin America, Mainland China, Middle East, North America, Northern Europe, Oceania, Central & Southern Asia, Southeast Asia, Western & Southern Europe |
