orange juice filling production line

Description



1.The filling machine is used in producing all kinds of juice with bottle.Washing ,filling,sealing can carried out on the same machine.The design of the machine is scientific and reasonable.



2.The appearance is beautiful and the function is complete.Its operation and maintenance is convenient.Its automation is high.



3.The advanced technology from Germany and Italy are employed.The speed of filling is fast and the liquid amount is controlled accurately.The filling device can be stopped automatically when there is no bottle or bottles are damaged.The advanced machine runs smoothly with low noise.



4.The magnetic torque is used for screw capping.The power of screw capping can be adjusted without steps.The power of the screw capping can,also be fixed,and the caps will not be damaged,the capping is reliable.



5.Horizon swirl air power caps sorting device is used to avoid damaging the surface of caps,and there is a shortage of caps in the caps storage tank,an alarm signal will be generated and the caps will be fed automatically.



6.The whole machine is controlled by PLC with touch-screen as the interface .



ATT: This filling machine can fill not only juices, but also coffee, green tea, flavoured water and any drinks which concentrate or powder shold be melt and mix with water.

Features: ---- orange juice filling production line( RCGF12-12-6)
1. This equipment is automatic washing filling capping three in one machine. It\'s of many advantages, such as compact structure, perfect control system and easy to be operated. Advanced touch screen and PLC control system makes man-machine communication true.
2. Washing part is mainly composed of washing pump, bottle clamps, water distributor, up turn-plate, guide rail, protection cover, spraying device, defrosting tray, rinse water take and rinse water refluxing tank.
3. Filling Part is mainly composed of filling tank, filling valves (hot and pressure filling), bottle hanging device / bottle pedestals, elevating device, liquid indicator, pressure gauge, filling pump, vacuum pump, etc.
4. Capping part is mainly composed of capping heads, cap loader (separated), cap unscrambler, cap drop rail, pressure regular, cylinder and also we need an air compressor as the auxiliary external equipment.
5. Main electrical components are all imported from world famous brands to guarantee excellent performance of the whole machine.
