Polycarbonate solid Sheet for skylight

Polycarbonate solid Sheet for skylight

Advantage:


1. Taiwan company,
2. 11 years solid produce experience
3. 100% Makrolon PC resin from Bayer in Germany
4. Certified by ISO 9001:2000,
5. 10years warranty
6. Italy Union UV-PC co-extrusion lines (5lines).
7. UV co-extrusion for long life-span
8. Light transmission rate up from 25%-88%.
   Customized colors and dimensions available upon request.

Specification:
1) Item Name: Polycarbonate sheet
2) Thickness: from 0.8mm to 12mm
3) Size: Max width: 2.1m, no limit on length
4) Color: Clear, Bronze, Blue, Lake-blue, Green, Grass-green, White, Red, Grey, Yellow, Purple, Orange, etc.
Features:
1) High transparency
2) UV-Protection
3) Light Weight
4) Impact Strength
5) Inhibiting Condensation
6) Thermal Insulation
7) Sound Insulation
8) Flame Resistance
9) Easy Installation
10) Enviromental Friendly


Technical features:
1) Impact strength: 850J/m. That means the impact resistance of polycarbonate solid sheet isabout 200 times of common glass, 20 times of acrylic sheets.
2) Light weight: About 1/2 times of glass .
2) Light transmission(clear color)80%--90% for different thickness
2) Light transmission: 80%-90% for different thickness of clear color
3) Specific gravity: 1.2 g/cm
4) Coefficient of thermal expansion: 0.065 mm/m°C
5) Service temperature range: -40°C to 120°C
6) Heat conductivity: 2.3-3.9 W/m2 °C
7) Tensile strength: >60N/mm2
8) Flexural strength: 100N/mm2
9) Modulus of elasticity: 2,400mPa
10) Tensile street at break: >65mPa
11) Elongation at break: >100%
12) Specific heat: 1.16J/kgk
13) Heat deflection temperature: 140°C
14) Soundproof index: 4mmthickness--27dB, 5mm--28dB, 6mm--29dB, 8mm--31dB, 10mm-32dB 12mm--34dB
