Polycarbonate hollow Sheet for skylight

Advantage:


1. Taiwan company,
2. 11 years solid produce experience
3. 100% Makrolon PC resin from Bayer in Germany
4. Certified by ISO 9001:2000,
5. 10years warranty
6. Italy Union UV-PC co-extrusion lines (5lines).
7. UV co-extrusion for long life-span
8. Light transmission rate up from 25%-88%.
   Customized colors and dimensions available upon request.

Key specifications:
1) Thickness: 4mm, 6mm, 8mm, 10mm, 12mm, 14mm, 16mm.
2) Standard width:2100mm;Standard Length 5800mm. 11800mm
3) Weight: 0.95/1.3/1.5/1.7,1.9, 2.2, 2.4, 2.6kg/m2
4) Colors: clear, blue, transparent, opal, green, bronze, etc.
5) Light transmission :70%--80%
6) Can provide one side or both sides surface 50um UV blocking layer
7) MOQ:1000SQM
8) Lead time:10 days
9) Payment: T/T or L/C at sight
Technical Features:
1)Light weight:4mm-0.95kg/sqm,6mm-1.3kg/sqm,8mm-1.5kg/sqm,10mm-1.7kg/sqm
2)High impact resistance
3)Good light transmission:70%-80% for clear color different thickness
4)Better heat insulation : Good heat insulation(K value):4mm-4.0W/m2K 6mm-3.6W/ m2K
8mm-3.3W/m2K 10mm-3.0W/m2K
5)UV blocking layer : 50μm ,can filter about 99% ultraviolet radiation in sunshine,It can prevent the resin fatigue or yellowing caused by the ultraviolet.
6)The minimum bend radii for different thickness with standard size(2100mm*5800mm)
4mm--700mm,6mm--1050mm,8mm--1400mm,10mm—1750mm
7)Simply processed and installed
8) Weather and UV resistant - properties retained for years. Temperature resistance range is -40° C ~ +120° C,
9) Flame resistance: High fire performance rating is class B1.
10) Sound and heat insulation: Superb sound insulation for freeway barrier and super thermal insulation save energy.
7) An engineering plastic of excellent integration capability. It has outstanding physical, mechanical, electrical and heat capabilities.


Applications:
1) Roofing light sheet and sunshade for office building, department store, hotel, stadium, school, amusement center, hospital, etc.
2) Skylight, lighting for corridors, balcony, passages and subway entries, walkways.
3) Do-It-Yourself (DIY), awning, canopy.
4) Advertising lamp boxes, sign board.
5) Anti-riot shield, bullet resistant material, Bank ATMs.
6) Conservatories, agricultural greenhouses, zoos, botanical gardens.
7) Industrial Roofing and Glazing
8) Swimming Pools roofing/cover/sheet
