Prismatic pattern light diffusion polycarbonate sheet

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Product Details

Basic Specification

Certification	ROHS,ISO9001:2008,CNAS
Quality	Grade A, Excellent
Guaranty	10 Years
UV coating	50um uv coating on surface
Material	100% raw Sabic or Bayer pc resin
Type	PC Solid Sheet

Detail Description

Prismatic polycarbonate light diffusion sheet

Specific gravity	1.2kg/m³
Impact strength	850J/m
impact strength of solid PC sheets is 250 times of glass,
20-30 times of PMMA sheet
Light transmission	80%-90% for different thickness of clear color

UV resistance	50μm UV layer, can filter 99% ultraviolet radiation in sunlight
Coefficient of thermal expansion	0.065 mm/m°c
Service temperature	-40°c to 120°c
Heat conductivity	2.3-3.9 W/m^2 °c
Tensile strength	>60N/mm²
Flexural strength	100N/mm²
Tensile street at break	>65mPa
Heat deflection temperature	140^oC

100% bayer/sabic material
Good light diffusing effect
Excellent weather resistance
High light transmission
10-year guarantee
Color: Clear, Red, Yellow, Green, Blue, Bronze, and customized.
Product Feature:

Astigmatism effect, cannot see the backlight
Combining with LED light can get the effect of color change
Good weather resistance and UV protection
Very high impact strength
Good light transmission
Lightweight, Simply installed
Meet different fire protection standard

Specifications:

Thickness: 1.5mm to 6mm
Maximum width: 2,100mm
Length: any dimension
Specific gravity: 1.2kg/m³

Techniacal Data:
Applications:

Advertising light boxes, signs
Outdoor billboards
LED lighting
Guides system
Light cover

Additional Information

Payment Terms	T/T, L/C, Western Union
Minimum Order	3 tons
Lead Time / Delivery Time	15 Day(s)
Sample Available	YES
Delivery Details	Both sides covered with PE protective film then packaged in the wooden pallets
FOB Port	Shanghai
Loading Info	By sea
Packing Info	Packed with kraft paper, and then in Pallet
Target Market(s)	Africa(except Middle East), Eastern Europe, Hong Kong/ Macao/ Taiwan, Japan & Korea, Latin America, Mainland China, Middle East, North America, Northern Europe, Oceania, Central & Southern Asia, Southeast Asia, Western & Southern Europe
