Aluminum Honeycomb Core Stretcher

  Aluminum Honeycomb Core Stretch Forming Machine
This machine is used for aluminum honeycomb core and honeycomb paper core stretch forming. In the production of cellular material,its function to pull even honeycomb core, each hole regular hexagon.It includes control systems, frequency conversion motor, drive reducer, bearing frame, linear guides, sliding beams, limit switch, jaws, etc.. Its features are: compact and easy to operate and improve production efficiency; lower stretch forming of aluminum honeycomb rejection rate.
Stretching the length and return rate  can be set, inverter control motor, automatic drawing and return of the speed and direction; with rotary encoder for feedback on the length of the control device.

Main technical indicators:
1. the device is mainly used for stretch forming of aluminum honeycomb products;
2. the applicable product range: checked according to the buyer’s request;
3. Size: hecked according to the buyer’s request;
4. installed power: 2.2KW;
5. Drawing speed 5 ~ 20mm / s;
6. The tension of expanding can be adjustable with the substrate thickness
7. according to the maximum tension design, F = 10KN;
