Aluminum Pasting Machine
Aluminum Pasting Machine is major equipment for making aluminum honeycomb core. After it accurately gelatinized aluminum foil multilayer stacking, heating press and stretching, the honeycomb structure core will be made. Using this machine can achieve the honeycomb core automatic producing, in order to promote the whole honeycomb structure equipment automatic, staff saving, quality guarantee, economize raw materials and increase efficiency. Making every effort to be that the customer costs down, oneself development lays a solid foundation for the customer and the enterprise.


Main Feature:
a. Automatic tension control of aluminum foil unwinding
b. Adjustment control of unwinding position
c.Automaticdeviation-rectifyingcontrol before aluminum foil gelatinize
d. Stove mouth deviation control
e. Needle roller and flatten synchronization control
f. Pre-set the operating parameter
g. Real-time display the operating parameter
h. Accurately cut the gelatinized aluminum foil, in order to stack assembly by head end.


Device Function:
a. Coating the J-71 or the same type adhesive on the honeycomb base material
b. The gravure roller should order in addition according to the buyer’s request.
c. Gelatinized honeycomb material through two temperature zone to dry
d. Meet the automatic cut-out for honeycomb material
e. Use wind to move the cut aluminum foil,automatic side head positioning.
f. It can setting number of layer presentation


Main technical Parameter:
a. Coating speed: 12~15m/min
b. Heating system:  room temperature ~ 150°С±5°С  ADJ
c.Aluminum foil base material width:  600mm
d.Cutting length: acmax 2500mm
e.Adhesive roller perimeter: 480 mm
f. Shearing length accurately: foil laminating size error ≯±0.2 mm
g.Total power input: 18KW/380V/50HZ
h.Equipment size:  machinery L8000×W900×H2500 mm
i.PLC control system. Control box size:  L600×W800×H1000 mm
