FR Alu composite panel line

Feature :
1. energy save . Normal acp product line , the core PE panels of acp forming by transport shelf to cooling before get ready for compound with both of aluminium sheet . but our existing line is compounding by heat resource of extruding the plastic with both of aluminium sheet . after producted acp strip-off is more strong than producted of normal acp product line;
2. easy operating . existing acp product line just set up on one control panel . and the operator just accords with required parameter to set up each control part is ok . needn\'t depend on the producted situation and adjustment any part . it is more easy for operating .
3. High goods percentage . depend on experience , the new acp product line could get 98% goods producted . it is get more 1%-1.5% goods percentage comparing previous acp product line .
4. low malfunction . we are processed all of electric parts by international brand . such as ABB , Siemens , Moeller, Schneider and so on . all of mechanical parts , it is processed by ourselives . they were approved in internal of our factory procedure to procedure . we are guaranteed quality !
Raw Material
A: PE Material: LDPE can be use recycle material
B: Aluminum Material (Colorful-paint Aluminum coil ):
Width:1240~1600mm
Thickness: 0.1~0.6mm
Maximum outer diameter: 1400mm
C. Adhesive Film: Width: 1250~1600mm
Thickness: 0.03~0.05mm
Weight: 60~80Kg/Roll
D. Protecting Film: Width: 1250~1600mm
Thickness: 0.06~0.08mm
Finished Product: Width: 1220~1575mm
Thickness: 2~6mm
Length: According to the customer’s requirement
Speed Rate of Manufacturing: 1~3m/min
Maximum Manufacturing Capacity of yearly : (300 days/year, 20 hours/day)
I type: Width 1220mm, 1,100,000 Square Meters
Width 1575mm, 1,400,000 Square Meters
Total Power of the Line: 561.6KW (new machine), actually work power is 280KW.
6. Total Air Consume: Pressure: 5~7Kgf/cm2
Consume: 0.5~1m3/min
7. Total Water Consume: Pressure: 1~2kg/cm2
Consume: 3 ton/day
8. Size of the Line:
length*width*height: 38m*7.5m*4m
9. Total Weight of the Equipments: 90 tons
