Basic Specification

Automatic N
Type Stretch Blow Moulding
Application Bottle

Detail Description

Product Description

It is applicable for blowing various soda pop bottles, mineral water bottles, medicine bottles, cosmetic bottles, tea and beverage bottles and other plastic bottles in various geometric shapes.
Feature:
1. The semifinished bottles are loaded automatically and enter the heating and drying tunnel automatically in order. The formed bottles are directly connected to the filling machine so that the customers need not buying costly bottle sorters.
2. Air-pressurized mold locking functions quickly and reliably, which ensures that the spew line of the bottle is beautiful and specific.
3. The high-end human-computer interface control system is adopted to ensure operational precision and stability.
4. Thesingle-unitcyclic heating design is adopted for the drying tunnel so that the central heating distance of rough bottles is small and the heating speed is quick.

Max. Blowing Volume 20L
Max. Productive Capacity 60-80p/h
Mould-clamping Pressure 8-40kg
Air Pressure 25-30kg
Max. Mould Size 500mm
Max. Mould Opening Stroke 520mm
Light of Bottle Preform 480mm
Electricy Power 18kw
Exterior Size   800x2300x1800(mm)
Oven 700x2000x1800x(mm)

Additional Information

Payment Terms T/T, L/C
Minimum Order 1 set
Lead Time / Delivery Time 30 Day(s)
Sample Available NO
FOB Port Shanghai
Target Market(s) Africa(except Middle East), Eastern Europe, Mainland China, Middle East, Central & Southern Asia, Southeast Asia
