Fireproof gypsum board for wall and ceiling
Your message must be between 20 to 2000 characters
Contact NowBasic Specification
| Surface | Green paper faced |
|---|---|
| Feature | Integrated |
| function | Moisture-Proof/dampproof, Waterproof |
| Type | Plasterboard Whole Ceiling |
| Shape | Square |
| material | plaster/Plasterboard |
Detail Description
Fireproof gypsum board
Description
It uses gypsum as the main material, adding fiber, bonding agents, modifiers, formed by suppressing, mixing and drying. It has the characteristics of fire sound insulation, heat insulation, light-weight, high-strength, small shrinkage, and the stability of small, non-aging, anti-moth-eaten. It can use nails, sawing, planning, adhesive and other methods of construction. It is widely used in ceiling, walls, interior walls,
Ingredient table
Name |
Figure |
Gypsum powder |
|
Gypsum retaining paper |
|
fiber |
|
citric acid |
|
starch |
|
vesicant |
|
others |
Features :
1) Produced by advanced German technology and equipment using high-purity gypsum as the raw material, Tincpro fireproof board bears flat surface, accurate dimensions and assured quality.
2) The imported high-quality original wood pulp covering paper has smooth face and high strength.
3) High amount of alkali-free fire-resistant glass fiber is added to board core, about 5-6 times more than that of standard plasterboard. The alkali-free fire-resistant glass fiber has a softening temperature of over 1000°C, effectively improving the stability of plasterboard in case of fire.
4)The density of board core is 20% higher than that of standard plasterboard; in addition, certain amount of fire retardant is added to board core, thus improving its strength in high temperature.
5) Test shows that the partition system composed of Tincpro plasterboard and light-weight steel stud has a fire-resistant limit of up to 4 hours.
Technical data:
1)Weight per unit: 9.5mm: 8.3kg/m2.
12mm: 9kg/m2
15mm: 11.8 kg/m2
2)Rupture load: 9.5mm: Vertical: 513N.
Horizontal: 171N.
12mm: Vertical: 684N.
Horizontal: 213N.
15mm: Vertical: 781N.
Horizontal: 281N.
3)Inner irradiation ratio: ≤1.0
4)Outer irradiation ratio: ≤0.1
5)Fire resistant temperature: 1000°C.
Specifications:
Standard size: 1200*2400mm
Length :1800mm to 3600mm
Width :1200mm&1220mm
Thickness :7mm to 15mm
Edge :Square Edge and Tapered Edge
Samples:
Additional Information
| Payment Terms | L/C, T/T |
|---|---|
| Minimum Order | 500pcs |
| Lead Time / Delivery Time | 20 Day(s) |
| Sample Available | YES |
| Delivery Details | after deposit,we start to produce,before shipping,the rest of money need to be paid |
| FOB Port | Qingdao |
| Loading Info | By sea. |
| Packing Info | Packed in bulk or pallet. |
| Target Market(s) | North America, Oceania, Southeast Asia, Eastern Europe, Africa(except Middle East), Hong Kong/ Macao/ Taiwan, Latin America, Japan & Korea, Middle East & South Asia, Mainland China, Western & Southern Europe, Northern Europe, Central & Southern Asia, Middle East |
