Lumbar Vertebra Traction Bed(LTD Display) RXPC-400A

The traction force, traction time, traction mode, angular angle and rotary angle are all controlled by micro-computer. LCD window display (Digital Display) and motor driven are intellectualized fully.
Applicable to the treatment of every kind of lumbar vertebra disease traction. Like lumbar illness lumbar disc projection, denaturation confusion, strain, dislocation ＆ in-complete paraplegia ＆ hemiplegia complicated symptoms. (Please use under the guidance of doctor)

Technical features:

1. Large LCD screen(LCD size:122×92cm) or digital display
2. 8 kinds of different traction mode(continuous mode, intermittent mode, cascade mode)
3. 20 kinds  of therapy methods memory
4. Auto compensatory function of traction force
5. Synchronous supervision of setting value and actual value
6. Several safety design (Max traction force 999N、the patient’s quick remote controller、the opperator’s quick remote controller、the operator’s quick reset button)

Technical parameters:

1. Power supply: 220V/50HZ
2. Power: 150W
3. Traction speed: ＜15mm/s
4. Traction force of lumbar vertebra:0-999N(adjustable)
5. Lumbar heating:37-60℃(adjustable)
6. Total time: 0-60min (adjustable)
7. Continuous time: 0-9min (adjustable)
8. Intermission time: 0-5min (adjustable)
9. Stage time: 5sec
10. Machine size:250×60×70cm
11. Weight: about 118kg
