Basic Specification
| color | colorful |
|---|---|
| size | 900*900mm 600*600mm 600*1200mm |
| Density | 18-22kg/m3 |
| intensity of wind | >8KPa(equal to the typhoon of 16 force) |
| Non-flammability | Grade B1 |
Detail Description
Exterior wall insulation decorative board
A thermal energy-saving decorative board with excellent thermal insulation properties, low thermal conductivity and stability, independent of temperature, humidity changes, but also has to prevent flooding, permeability and other characteristics, so that the whole building respiratory function, so that constant temperature and humidity, the effect of constant oxygen.
Structure
1. Performance index
2. Basic specification
3. Main indexes
4. Installation standard
Installation process
1）posit the reference line to ensure installation formally.
2）deploy the silicone sealant glue equality by using machine.
3) Paste the cement mortar. It means paste the finished cement mortar on the wall combining surface around the frame evenly, and then hit five points in the middle of uniform to keep it more fastness.
4) Put the wall board one the wall which is posited reference line, and then use the glue hammer to hit all round lightly, to confirm it keep evenly and completely.
5) Paste textured paper through the board edge, which is required to be smooth, vertical and horizontal, leaving side. To prevent the pollution from the glue
6) Stick on the first silicone sealant
This step can wrapped the anchor into the silicone sealant to protect the anchor.
7）Install anchor
After paste the wall board 24 hours, hit a hole with hole punch on the four board of adjacent cross location. And then install the anchor to ensure reinforcement.
8）Stick on the second silicone sealant
Using the glue gun to spray the uniform amount of the glue into the dividing joint , and then use the \"U\" shaped blade to scrap the rest glue. After construction should be took the paper tape off within an hour.
9）Cleaning the board , removing the protective film
10）Project acceptance
Patterns showing
Nine outstanding traits of EPS insulation exterior wall board.
1. Environmental protection
2. Energy-saving
3. Fire prevention.
4. Lightweight and reliability
5. Ageing-resistant and good associability
6. Extraordinary waterproofing
7. Security
8. Simple construction and high performance price ratio
9. Flexible and convenient production
Using palce
EPS panels are widely used in construction, insulation, packaging, frozen, daily necessities, industrial casting etc. And also can be used to exhibition venue, cabinet, advertising signs and toys making. At present, in order to meet the national building energy efficiency requirements, the boards are mainly used in the wall exterior insulation, wall insulation, floor heating.
A thermal energy-saving decorative board with excellent thermal insulation properties, low thermal conductivity and stability, independent of temperature, humidity changes, but also has to prevent flooding, permeability and other characteristics, so that the whole building respiratory function, so that constant temperature and humidity, the effect of constant oxygen.
Structure
1. Performance index
| Non-flammability : | Grade B1 |
| Density | 18-22kg/m3 |
| thermal conductivity | <=0.041 /w/(m.k |
| Water absorption | <=50g/m2 |
| water permeability | there is no drop of water to emerge on the back |
| dimension error | <=0.3% |
| intensity of pulling resistance Perpendicular to the surface | >=0.2Mpa |
| Intensity of impact resistance | >=15J |
| Water vapor Permeability | <=4.5ng/(m.s.pa) |
| tensile adhesive strength | 0.21mpa |
| Anchor pullout force | 0.38KN |
| Water vapor permeation resistance | 29700m2.H.Pa/g |
| The weight per square meter | 18.3kg/m3 |
| intensity of wind resistance | >8KPa(equal to the typhoon of 16 force) |
2. Basic specification
| size: | 900*900mm 600*600mm 600*1200mm |
| The thickness of the whole panel: | 20-100mm |
| The thickness of the surface layer: | 3-5mm |
| smoothness: | +-1.5mm/m |
| form and position tolerance of four sides: | +-1.0mm |
3. Main indexes
| The weight of the finished wall panel layer: | grade B1-B2 6kg/m3-10kg/m3 |
| grade A1 10kg/m3-15kg/m3 | |
| Impermeability pressure: | In line with the requirements of JG-149-2003 |
| Freezing and thawing coefficient: | In line with the requirements of JG-149-2003 |
| The thermal insulation coefficient: | In line with the requirements of GB/T10295-2008 |
| Surface treatment: | Natural |
| paved with Inorganic pigment | |
| Electrostatic spray |
4. Installation standard
| The height difference between the two adjacent panels | +-1.5mm |
| The width of the gap between two structural panels | 12mm |
| The depth of the Mortar in the gap | >=5mm |
| Smoothness of the surface: | 5mm/4m |
Installation process
1）posit the reference line to ensure installation formally.
2）deploy the silicone sealant glue equality by using machine.
3) Paste the cement mortar. It means paste the finished cement mortar on the wall combining surface around the frame evenly, and then hit five points in the middle of uniform to keep it more fastness.
4) Put the wall board one the wall which is posited reference line, and then use the glue hammer to hit all round lightly, to confirm it keep evenly and completely.
5) Paste textured paper through the board edge, which is required to be smooth, vertical and horizontal, leaving side. To prevent the pollution from the glue
6) Stick on the first silicone sealant
This step can wrapped the anchor into the silicone sealant to protect the anchor.
7）Install anchor
After paste the wall board 24 hours, hit a hole with hole punch on the four board of adjacent cross location. And then install the anchor to ensure reinforcement.
8）Stick on the second silicone sealant
Using the glue gun to spray the uniform amount of the glue into the dividing joint , and then use the \"U\" shaped blade to scrap the rest glue. After construction should be took the paper tape off within an hour.
9）Cleaning the board , removing the protective film
10）Project acceptance
Patterns showing
Nine outstanding traits of EPS insulation exterior wall board.
1. Environmental protection
2. Energy-saving
3. Fire prevention.
4. Lightweight and reliability
5. Ageing-resistant and good associability
6. Extraordinary waterproofing
7. Security
8. Simple construction and high performance price ratio
9. Flexible and convenient production
Using palce
EPS panels are widely used in construction, insulation, packaging, frozen, daily necessities, industrial casting etc. And also can be used to exhibition venue, cabinet, advertising signs and toys making. At present, in order to meet the national building energy efficiency requirements, the boards are mainly used in the wall exterior insulation, wall insulation, floor heating.
