Contact NowBasic Specification
| uesd for | prefab house |
|---|---|
| outer layer | mgo board |
| Place of Origin | CHINA |
| inner layer | EPS |
| size and thickness | customized |
| Material | Magnesium Board |
| Thickness | 20-100mm |
Detail Description
MGO SIP Panel --the best substitute of osb and cement panel
Material |
outer layer:Mgo board |
|
inner layer: Polystyrene, XPS material XPS: good insulation materials |
Specification |
The size and thickness could be made according to customized. |
Color |
White,Red, Blue, etc. |
Feature |
Sound insulation and keep warm |
|
Fireproof: A grade non-combustible mgo board and flame retardant-grade EPS and XPS |
|
Green and environment protection |
|
Easy to construct, save the cost of installation. |
Specification
Common size: 900*2100, 600*2100
1) Largest width: 1200mm, adviced 900mm
2) Length: 2400mm, 2700mm, 3000mm, 3600mm, option is available
3)Thickness:20-100mm
4)Mgo board thickness:3-20mm
5)EPS Density: 15-25KG/M3
Customized size can be accepted.
Characteristics
a. A finished product, can be used directly, no need to compound.
b. Lower the cost and time of construction.
c. Superior fireproof wallboard.
d. Good performance of sound insulation and keep warm.
e. Green and environment protection.
f. Easy to construct and combine discretionarily.
Structure
Application
Simple mobile house, cold storage, warm-keeping houses, villa, prefabricated house and thermal insulation wallboard. It can also be used in flue pipe making.
Additional Information
| Payment Terms | L/C, T/T |
|---|---|
| Minimum Order | 50 pieces |
| Lead Time / Delivery Time | 20 Day(s) |
| Sample Available | YES |
| Delivery Details | 20 day within receipt of deposit |
| FOB Port | Shanghai |
| Loading Info | transported by vessels or trains according to your requests |
| Packing Info | packed in bulk or with pallets |
| Target Market(s) | Africa(except Middle East), Central & Southern Asia, Eastern Europe, Hong Kong/ Macao/ Taiwan, Japan & Korea, Latin America, Mainland China, Middle East, North America, Northern Europe, Oceania, Southeast Asia, Western & Southern Europe |
